High Precision Wedge Wire Screen Filter Elements

WDJ High Precision Wedge Wire Screen Filter Elements

Overview

High precision wedge wire filter elements adopt international mainstream V-shaped trapezoidal wire fully automatic CNC fusion welding technology, integrally precision-made of 316L stainless steel. Strictly designed in accordance with international high-end industrial filtration standards and mature industry process systems, the products continuously optimize structural accuracy, self-cleaning performance and durability. Featuring anti-clog narrow-outside & wide-inside gap, high pressure & temperature resistance and long-cycle stable operation, they are widely applied in fine chemical, industrial fluid, water treatment, power plant, mining, marine and other general industrial scenarios, providing stable and reliable precision filtration solutions for various industrial equipment with cost-effective price, short delivery cycle and full-range customized services.

Core Tech & Parameters

- Structure & Technology: CNC precision wire winding, integral fusion welding, full-size precision inspection via 2.5D image measuring instrument

- Main Material: 316L stainless steel (Duplex steel, Hastelloy optional)

- Wire Strength: 1200~1300MPa, stable and deformation-resistant structure

- Working Pressure: Max. 3.2MPa

- Working Temperature: Max. 300℃

- Filtration Rating: Full range of 15μm~300μm

- Particle Removal Efficiency: ≥99% (particles ≥25μm)

- Industrial Service Life: 4~5 years long-term operation for industrial overhaul

- Backwash Performance: Repeated backwash available, anti-clog, no delamination and no falling off

Application Value

1. Comply with international high-end filtration process standards, perfectly adapting to various imported industrial filtration equipment systems;

2. Greatly reduce equipment operation and procurement costs, with delivery cycle shortened by more than 50%;

3. Strong adaptability to industrial working conditions, enabling stable equipment operation for more than 3 years;

4. Low pressure difference and low energy consumption, simple daily maintenance and lower operating cost;

5. Support personalized customization of full size, interface, precision and material to adapt to all-industry working conditions.

Application Industries

Fine chemical, industrial fluid filtration, polymer filtration, industrial circulating water treatment, cooling water, wastewater treatment, power plant, mining, marine, food & pharmaceutical, environmental protection equipment

Service & Support

Drawing confirmation, sample testing and accurate working condition matching; Equipment cleaning, maintenance, precision inspection and full-set technical support; 24-hour rapid after-sales response with on-site commissioning service available; Complete quality certificates, test reports and product qualification certificates provided.
